Products

Explore our extensive range of products and systems, from curtain walls and entrances to framing systems and windows. With solutions for hurricane resistance, sun control, blast mitigation and thermal performance, our products meet the unique demands of any project, from healthcare, education and office facilities to art and leisure, civic and public, retail and more.

If you know the product name you’re looking for, simply click on the Products A-Z link.

Clear All
Product
arrow icon
Performance/Features
arrow icon
Thermal Performance
Seismic Tested
Hurricane Resistance
Blast Mitigation
Door Stile Width
AAMA Class. – Wdw/Dr.
Dimensions
arrow icon
Sightline
Application Height
System Depth
Glazing
arrow icon
Glazing Method
Glass Plane
Glazing Installation
Glazing Infill
View

Trifab® VersaGlaze® 451/451T Framing System arrow icon
  • 2″ (50.8mm) sightline
  • 4-1/2″ (114.3mm) depth
  • High-thermal performance
  • Front, center, back or multi-plane glass applications
  • Blast mitigation (451T), hurricane resistance
  • Structural silicone glazed (SSG) options, pre-glazed options

standard entrances
190/350/500 Standard Entrances arrow icon
  • 2-1/8″ (54mm), 3-1/2″ (87.9mm) or 5″ (127mm) sightline
  • 1-3/4″ (44.5mm) depth
  • Non-thermal performance
  • Moderate- to high-traffic application

curtain wall system
1600 Wall System®1 Curtain Wall arrow icon
  • 2-1/2″ (63.5mm) sightline
  • 6″ (152.4mm), 7-1/2″ (190.5mm) or 10-1/2″ (267mm) depth
  • Thermal performance
  • Seismic (AAMA 501.4 and 501.6 standards)
  • Low- to mid-rise applications
  • Blast mitigation, hurricane resistance

Trifab VersaGlaze 450 Framing System
Trifab® VersaGlaze® 450 Framing System 1-3/4″ sightline arrow icon
  • 1-3/4″ (44.5mm) sightline
  • 4-1/2″ (114.3mm) depth
  • Non-thermal performance
  • Front, center, back or multi-plane glass applications
  • Structural silicone glazed (SSG) options

Trifab VersaGlaze 450 Framing System 2 inch sightline
Trifab® VersaGlaze® 450 Framing System 2″ sightline arrow icon
  • 2″ (50.8mm) sightline
  • 2-1/4″ (57.2mm) frame depth (Veneer) and 4-1/2″ (114.3mm) frame depth (captured)
  • Non-thermal performance
  • Front plane glass applications
  • Structural silicone glazed (SSG) options

Double Pane
1600UT System™1 Curtain Wall arrow icon
  • 2-1/2″ (63.5mm) sightline
  • 6″ (152.4mm), 7-1/2″ (190.5mm) or 10-1/2″ (266.7mm) system depth with 1” double-pane infill
  • 6-3/4″ (171.5mm), 8-1/4″ (209.6mm) or 11-1/4″ (285.8mm) system depth for triple-pane 1-3/4″ (44.5mm) infill
  • Seismic (AAMA 501.4 and 501.6 standards)
  • Blast mitigation, storm shelter (ICC 500)

system 2 curtain wall
1600UT System™2 Curtain Wall arrow icon
  •  2-1/2″ (63.5mm) sightline
  • 6″ (152.4mm), 7-1/2″ (190.5mm) or 10-1/2″ (266.7mm) system depth with 1” double-pane infill
  • 6-3/4″ (171.5mm), 8-1/4″ (209.6mm) or 11-1/4″ (285.8mm) system depth for triple-pane 1-3/4″ (44.5mm) infill
  • Ultra-thermal performance
  • Seismic (AAMA 501.4 and 501.6 standards)
  • Vertical Structural Silicone Glazed (SSG)

insulpour thermal entrances
250T/350T/500T Insulpour® Thermal Entrances arrow icon
  • 2-1/2″ (63.5mm), 3-1/2″ (88.9) or 5″ (127mm) sightline
  • 2-1/4″ (57.2mm) depth
  • High-thermal performance
  • Blast mitigation, hurricane resistance
  • Moderate- to high-traffic applications
  • 1″ and 1-1/2″ glazing options
  • IsoPour™ Thermal Break technology
  • Dual finish option
